● UL Listing: UL Listed – 3 hour Fire Rating.
● Material: Brass
● Finish: Standard finish US26D (Satin Chrome Plated): no MOQ requirement. Other finishes (US3, US15, US5, US26, US10B) are available upon request, however, require MOQ 2,000 sets for each sku.
● Customer logo is accepted, however, OEM order requires MOQ 2,000 sets for each sku.
● Features: Ease of installation, Automatic snaps-closed lever.
● Non-handed.
● Description: a. Each set includes 1 Steel Rod, 1 Steel Rod Tip, Steel Strikes, mounting screws. b. 2 sets packed in one box; 50 boxes packed in one carton. (Gross weight: 17kg per carton)
● Sizes:
12” Standard Rod length measured from the center of the bolt body to the bolt tip. (Other rod lengths are available upon request.)
● Size of face: 6-3/4” (171mm) x 1” (25mm).
● Rod length: 10.5” (265mm) as standard.
● Mounting hole location: 6-1/4” (159mm).
● Bolt throw is 3/4” (19mm) with a 7/8” vertical adjustment.
● Bolt backset is 3/4” (19mm).
